Stainless steel decolour degrease hydraulic horizontal pressure 0.4Mpa leaf filters
Product competitive advantage:
1, Fully hermetic filter , no leakage, no pollution
2, Filtering gauze flakes can be pulled out automatically, and easy to be inspected and cleaned.
3, As the leaves filtering on both sides, large filtration area and solids holding capacity can be obtained.
Product description:
This product is of novel design, the main body of filter consists of filtration tank, screen, end-plate pullout device, automatic dreg discharging device, etc.
During filtering, the filter aid is mixed up with material in the mixing cylinder then transmitted by pump onto the filter screen to form a filter cake layer.
Once the stable filter cake is realized, the minute filter aid particles provide countless micro passages, which entrap the suspended impurity and let the clear liquid through. Therefore the real filtration is realized through the cake layer.
In case that the filter cake over the surface of filter screen reaches certain thickness, the feeding shall be stopped, and compressed air or steam shall be employed to blow dry the cake, and clean the filter screen the discharge ,
the vibration dreg discharging device shall be switched on, the dregs shall be unloaded because of weight and vibration. As to sticky filter cake, manual help shall be provided to clean up the dregs.
Introduction of Company:
Juneng Group employs a team of well-trained professional, adopts advance EPR production management model in cooperation with state–of–the–art apparatus and process i.e. CNC Turner, Machine Center, Highly Accuracy Test Instrumentation, Quality and Process Control System to ensure quality, stability, and reliability of every product.
Application:
Food industry : Syrups, edible oils, dewaxing , decolour, degrease
Chemical industries: Sulphur, aluminum sulfate, Polyaluminum chloride, plastic, dyestuff intermediate, bleaching liquid, lubricant additives and intermediate and high pressure polyethylene, etc.
Dry, semidry cake and clean filtrate recovery.
Product Specifications:
| Area series ( ㎡) | Shell diameter series ( mm) | Work pressure ( Mpa) | Work temperature
(℃) | Proximate treatment
capacity (T/H·㎡) |
| 5, 10, 15, 20, 25, 30, 35, 40,
45, 50, 60, 70, 80, 90, 100, 120,
140, 160, 180, 200 | 900, 1200, 1400, 1500, 1600,
1700, 1800, 2000 | 0.4 | 150 | Oil | 0.2 |
| | | Beverage | 0.8 |
Why Choose Juneng brand
1. International High quality Certification production chain .
2. Manufacturer, more reasonable price .
3. Solid technical support and after-sales service.
